A new Side Chat Episode of the Tech Informative is now live on YouTube. In this episode we are covering HPE Integrated Lights-Out, also known as HPE iLO.
The Tech Informative is a video podcast by Stephen Wagner and Rob Dalton that hopes to explore everyday technologies from the perspective of Information Technology professionals.
Rob Dalton is a lover of IT and a Director by profession. Rob considers himself a jack of all trades, an IT veteran, and is also the author of “Secured Packets”, a technology blog with a focus on security. Rob’s blog can be found at: https://www.securedpackets.com
Did a new VM appear on your VMware vSphere cluster called “vCLS”? Maybe multiple appeared named “vCLS (1)”, “vCLS (2)”, “vCLS (3)” appeared.
This could be frightening but fear not, this is part of VMware vSphere 7.0 Update 1.
What is the vCLS VM?
The vCLS virtural machine is essentially an “appliance” or “service” VM that allows a vSphere cluster to remain functioning in the event that the vCenter Server becomes unavailable. It will maintain the health and services of that cluster.
Where did the vCLS VM come from?
The vCLS VM will appear after upgrading to vSphere 7.0 Update 1. I’m assuming it was deployed during the upgrade process.
It does not appear in the standard Cluster, Hosts, and VMs view, but does appear when looking at the vSphere objects VM lists, Storage VM lists, etc…
Is it normal to have more than one vCLS VM?
The vCLS VMs are created when hosts are added to a vSphere Cluster. Up to 3 vCLS VMs are required to run in each vSphere Cluster.
The vCLS VMs will also appear on clusters which contain only one or two hosts. These configurations will result in either 1 or 2 vCLS VMs named “vCLS (1)” and “vCLS (2)”.
A note on licensing in regards to the vCLS VM
For VMware environments that use VM based licensing like vSphere for ROBO (Remote Office Branch Office), vCLS VMs are shown in the licensing interface as counting towards licensed VMs. Please Note that these VMs do not official count towards your purchased licenses as these are VMware System VMs. Please read VMware KB 80472 for more information on this.
More Information on vCLS VMs
For more information and technical specifics, you can visit the link below:
Originally when an environment was configured with an Nvidia GRID K1 or K2 card, not only does the card provide 3D acceleration and rendering, but it also offloads the VMware BLAST h264 stream (the visual session) so that the CPU doesn’t have to. This results in less CPU usage and provides a streamlined experience for the user.
This functionality was handled via NVFBC (Nvidia Frame Buffer Capture) which was part of the Nvidia Capture SDK (formerly known as GRID SDK). This function allowed the video card to capture the video frame buffer and encode it using NVENC (Nvidia Encoder).
Ultimately after spending hours troubleshooting, I learned that NVFBC has been deprecated and is no longer support, hence why it’s no longer functioning. I also checked and noticed that tools (such as nvfbcenable) were no longer bundled with the VMware Horizon agent. One can assume that the agent doesn’t even attempt to check or use this function.
Before I was aware of this, I noticed that while 3D Acceleration and graphics were functioning, I was experiencing high CPU usage. Upon further investigation I noticed that my VMware BLAST sessions were not offloading h264 encoding to the video card.
You’ll notice above that under the “Encoder” section, the “Encoder Name” was listed as “h264 4:2:0”. Normally this would say “NVIDIA NvEnc H264” (or “NVIDIA NvEnc HEVC” on newer cards) if it was being offloaded to the GPU.
Looking at a VMware Blast session (Blast-Worker-SessionId1.log), the following lines can be seen.
You’ll notice it tries to load the proper functions, however it fails.
Unfortunately the only solution is to upgrade to newer or different hardware.
The GRID K1 and GRID K2 cards have reached their EOL (End of Life) and are no longer support. The drivers are not being maintained or updated so I doubt they will take advantage of the newer frame buffer capture functions of Windows 10.
Newer hardware and solutions have incorporated this change and use a different means of frame buffer capture.
To resolve this in my own homelab, I plan to migrate to an AMD FirePro S7150x2.
A joint project of mine with Rob Dalton, The Tech Informative is a video podcast on YouTube dedicated to everything tech with a focus on corporate IT.
We intend to keep it informal, fun, and packed full of handy and useful information.
Check it out, and don’t forget to like and subscribe. We also appreciate suggestions and feedback!
This introduction episode is the first of many to come!
